AsRock H610M-HVS/M.2 R2.0 matična ploča cene

• CPU

Supports 13th Gen & 12th Gen Intel® Core™ Processors (LGA1700)
7 Power Phase design
Supports Intel® Hybrid Technology
Supports Intel® Turbo Boost Max 3.0 Technology

• Chipset

Intel® H610

• Memory

Dual Channel DDR4 Memory Technology
2 x DDR4 DIMM Slots
Supports DDR4 nonECC, unbuffered memory up to 3200
Supports ECC UDIMM memory modules (operate in nonECC mode)
Max. capacity of system memory: 64GB
Supports Intel® Extreme Memory Profile (XMP) 2.0

• BIOS

128Mb AMI UEFI Legal BIOS with multilingual GUI support
ACPI 6.0 Compliant wake up events
SMBIOS 2.7 Support
CPU Core/Cache, CPU Core/Cache LoadLine, CPU GT, CPU GT LoadLine, DRAM, +0.82V PCH, +1.05V PCH, VCCIN AUX, +1.8V PROC, +1.05V PROC Voltage Multiadjustment

• Graphics

Intel® Xe Graphics Architecture (Gen 12)
Dual graphics output: support HDMI and DSub ports by independent display controllers
Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
Supports DSub with max. resolution up to 1920x1200 @ 60Hz
Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible Port

* Intel® UHD Graphics Builtin Visuals and the VGA outputs can be supported only with processors which are GPU integrated.

• Audio

7.1 CH HD Audio (Realtek ALC897/887 Audio Codec)
Supports Surge Protection

• LAN

PCIE x1 Gigabit LAN 10/100/1000 Mb/s
1 x Realtek RTL8111H
Supports WakeOnLAN
Supports Lightning/ESD Protection
Supports Energy Efficient Ethernet 802.3az
Supports PXE

• Slots

CPU:
1 x PCIe 4.0 x16 Slot (PCIE2), supports x16 mode*
Chipset:
1 x PCIe 3.0 x1 Slot (PCIE1)

*Supports NVMe SSD as boot disks

• Storage

Chipset:
1 x Ultra M.2 Socket (M2_2, Key M), supports type 2242/2260/2280 PCIe Gen3x4 (32 Gb/s) mode*
4 x SATA3 6.0 Gb/s Connectors

*Supports NVMe SSD as boot disks
Supports ASRock U.2 Kit

• Connector

1 x SPI TPM Header
1 x Chassis Intrusion and Speaker Header
1 x CPU Fan Connector (4pin)*
1 x Chassis/Water Pump Fan Connector (4pin) (Smart Fan Speed Control)**
1 x 24 pin ATX Power Connector
1 x 8 pin 12V Power Connector
1 x Front Panel Audio Connector
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)

*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
** The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
CHA_FAN1/WP can auto detect if 3pin or 4pin fan is in use.

• Rear Panel I/O

1 x PS/2 Mouse/Keyboard Port
1 x DSub Port
1 x HDMI Port
2 x USB 3.2 Gen1 Ports (Supports ESD Protection)
4 x USB 2.0 Ports (Supports ESD Protection)
1 x RJ45 LAN Port with LED (ACT/LINK LED and SPEED LED)
HD Audio Jacks: Line in / Front Speaker / Microphone

• Software and UEFI

Software
ASRock Motherboard Utility (ATuning)
ASRock XFast LAN
UEFI
ASRock EZ Mode
ASRock Full HD UEFI
ASRock My Favorites in UEFI
ASRock Instant Flash

*These utilities can be downloaded from ASRock Live Update & APP Shop.

• Support CD

Drivers, Utilities, AntiVirus Software (Trial Version)

• Accessories

Quick Installation Guide, Support CD, I/O Shield
2 x SATA Data Cables
1 x Screw for M.2 Socket

• Hardware Monitor

Fan Tachometer: CPU, Chassis/Water Pump Fans
Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans
Fan MultiSpeed Control: CPU, Chassis/Water Pump Fans
CASE OPEN detection
Voltage monitoring: CPU Vcore, DRAM, +0.82V PCH, +1.05V PCH, VCCIN AUX, VCCSA, +1.05V PROC, +12V, +5V, +3.3V

• Form Factor

Micro ATX Form Factor: 8.66in x 7.6in, 22.0 cm x 19.3 cm
Solid Capacitor design

• OS

Microsoft® Windows® 10 64bit / 11 64bit
