Wider Coverage Sharper Focus
4 Channel Wireless HD Video Security Kit
Connection with Wirefree
Easy Monitoring and Networking
The Network Video Recorder and cameras adopt WiFi connections, which free you from laying Ethernet cables, make it easy to install and extend, save your time, energy and money.
Wider Coverage and Stronger
Throughwall Capability
The routerlevel independent WiFi chip, dual high gain antennas and Tenda's professional wireless transmission technology boosts stable and strong signal. It is able to produce clear and smooth image when the WiFi signal covers a radius of 200m in an open environment or passes through 3 walls indoors.
Automatic and Fast Connection
No More Complicate Settings
After being powered on, the NVR automatically search, find and add cameras, the convenient and fast networking requires no manual operation.
*The camera needs to be in factory settings
High Pixel HD Video Recordings
Clear and Full Details of the Video
The upgraded 3MP (23041296) HD camera captures clear and delicate monitoring image, bringing more details and a brandnew visual experience.
Smotion Detection and Target Recognition
Accurate Alarm and Less Harassment
Based on deep learning image identification technology, the cameras accurately recognize figure movement.
Nonhuman targets are filtered, thus greatly improving alarm accuracy.
Dual spotlights and Dual Infrared Lights
Clear and Colorful Even at Night
Equipped with two highpower spotlights and two IR lights, and high sensitive image sensors, your night vision is now lit up and in fullcolor. There are three available night vision modes: Smart Mode, Fullcolor Mode, and Black & White Mode.
Sound and Light Alarm Deter Intruders
When intrusion is detected during the alarming period, a sound and white flashing light alarm will be triggered to warn illegal intruders. At the same time, the alarm message will be sent to the TDSEE App to promote security.
View Videos on Your Mobile Phone at Any Time
Fully Control of Abnormal Status
You can view the video on your mobile phone anytime and anywhere, and feel at ease when you away from home. Alarm messages are pushed in time, you can control abnormal status in real time.
Video and Audio Input
IP Video Input: 4ch
IP Video Resolution: Up to 3MP
Input Bandwidth: 60 Mbps
Output Bandwidth: 60 Mbps
Video and Audio Output
HDMI Output: 1ch, 1920 1080p/60Hz, 1280 1024/60Hz, 1280 720/60Hz
VGA Output: 1ch, 1920 1080p/60Hz, 1280 1024/60Hz, 1280 720/60Hz, HDMI/VGA simultaneous output
Video and Audio Decoding:
Video Decoding Format: H.265, H.264
Audio Decoding Format: G.711A
Recording Resolution: 3MP, 1080p, UXGA, 720p, VGA, nHD, 4CIF, CIF
Decoding Capability: 4ch@1080p (30 fps)
Stream Type: Video, Video and Audio
Recording Management
Record Mode: Normal, Alarm
Playback Mode: Instant, Channel, File, Tag
Sync Playback: Up to 4ch
Backup Mode: USB device
Network Management
Ethernet Port: 1 RJ45, 10Mbps/100Mbps autonegotiation Ethernet port
Network Protocol: TCP/IP, IPv4, RTSP, UDP, NTP, DHCP
Mobile Client: Supports iOS, Android
Wireless Specification
Wireless Standard: IEEE 802.11b/g/n
Frequency: 2.4 GHz
Antenna: Dual external antennas
Transmission Rate: Up to 144 Mbps
HDD Storage
HDD Interface: 1 SATA 3.0 interface
Capacity: Up to 10 TB capacity for each HDD
External Interface: USB Port 1 x USB 2.0
Generals
Power: 12 V DC, 2 A
Dimension: 200 mm 200 mm 48 mm (7.9 7.9 1.9)
Weight (Without HDD): 510 g (1.13lb)
Certification: CCC, SRRC, CE, FCC, RoHs
Installation Method: Desk mounting, wall mounting
Temperature:
Operating Temperature: 0C 40C (32F 104F)
Storage Temperature: 30C 70C (22F 158F)
Humidity:
Operating Humidity: 10% 90% RH (noncondensing)
Storage Humidity: 5% 95% RH (noncondensing)
WiFi Camera
Image Sensor: 1/2.7 CMOS sensor
Max. Resolution: 2304 x 1296
Day and Night: ICR type
Digital Noise Reduction: 3D DNR
Digital Wide Dynamic Range: Support
Backlight Compensation: Support
Supplementary Light: 2 IR lights, 2 spotlights
Infrared Supplementary Light Distance: 30 meters (depending on environment)
Night Vision Mode: Smart Mode, Full Color Mode, Black and White Mode
Lens Specifications
Lens Type: 4
[email protected]FOV: Horizontal FOV: 86.1, Vertical FOV: 46, Diagonal FOV: 104
Video Specifications
Video Encoding Format: H.265
Main Stream: 15fps (2304 1296, 1920 1080, 1280 720, 640 360)
Sub Stream: 15fps (640 360, 352 288)
Audio Specifications
Audio Encoding Format: G.711A
Audio Sampling Rate: 8 kHz
Network Management
Ethernet Port: 1 RJ45, 10Mbps/100Mbps autonegotiation Ethernet port
Wireless Specification
Wireless Standard: IEEE 802.11b/g/n
Frequency: 2.4 GHz
Transmission Rate: Up to 144 Mbps
Antenna
Dual external antennas
Smart Alarm: Motion Detection
Support: Smotion Detection
Support: Sound and Light Alert
Support: External Interface
Audio Input: Builtin MIC
Audio Output: Builtin speaker
Button: 1 x Reset button
LED Indicator: 1 x Dual color (red and blue) LED indicator
General
Power: 12 V DC, 1 A
Dimension: 175 mm x 72 mm x 72 mm (6.9 2.9 2.9)
Weight: 226 g (0.5lb)
Protection Level: IP66
Installation Method: Wall mounting, ceiling mounting
Certification: CE, FCC, RoHs
Temperature:
Operating Temperature: 30C 60C (22F 140F)
Storage Temperature: 40C 70C (40F 158F)
Humidity:
Operating Humidity: 10% 95% RH (noncondensing)
Storage Humidity: 3% 95% RH (noncondensing)
Kit:
Dimension: 305 mm x 305 mm x 280 mm (12 12 11)
Weight: 3.1 kg (6.84lb)
Package Contents:
WiFi Network Video Recorder x 1
Power adapter (12 V 2 A) x 1
Screw kit (WiFi network video recorder) x 1
Mouse x 1
Quick installation guide x 1
WiFi Cameras x 4
Power adapters (12 V 1 A) x 4
Screw kits (WiFi camera) x 1
Installation templates x 4
Waterproof kits x 4
