Qualcomm Chipset Inside Up to 867Mbps on 5GHz Up to 300Mbps on 2.4GHz High Power PA For 2.4GHz&5GHz 2 x Gigabit Ethernet Ports IEEE802.3at/af PoE Power Supply Ceiling/Wall Mount support Hardware Speci?cations: Chipset: QCA9531; DDR: 64MB; Flash: 16MB Antenna: Built in 2*3dBi Antenna Wireless Standard: IEEE802.11b/g/n RF Parameters: Output Power (Max): 80mW (19dBm); Receiving Sensitivity (Max): 96dBm; Frequency: 2.4GHz2.4835GHz Modulation Mode: DSSS: DBPSK@1Mbps, DQPSK@2Mbps,
[email protected]/11Mbps; OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16QAM@24Mbps, 64QAM@48/54Mbps; MIMOOFDM: MCS 015 Transmission Rate: 11b: 1, 2, 5.5, 11Mbps; 11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps; 11n: MCS0MCS15(20MHz and 40MHz Analog Bandwidth); 20MHz: 144.4Mbps; 40MHz: 300Mbps Physical Ports: 1* 10/100Mbps WAN RJ45 Ethernet Port; Support POE Power Supply; 1* 10/100Mbps LAN RJ45 Ethernet Port; Support POE Power Supply; 1* RESET / WPS Button Indicator: Three Color Indicator Power Supply: 802.3af/802.3at POE Power Supply(0100m); Power Adapter: 48V 0.32A POE Power Adapter(Con?gured) Power Consumption 250000H Installation Way Ceilingmounted/Wallmounted Case Plastic Case(Imported ABS Material) Physical Features Size: 200*200*18mm; Weight: 0.32Kg Working Environment: Working Temperature: 10 C65 C Storage Temperature: 40 C70 C Operation Humidity: 10%90%RH Noncondensing Storage Humidity: 5%90%RH Noncondensing EAN: 6971690792015
